ATOZ Series

ATOZ Series features

  • None-Side-Force Injection System mechanism design
  • Precise patened 4-cylinder direct clampig unit
  • Using linear guide for clamping and injection unit
  • Short machine length, high space utilization


Specifications of  ATOZ Series injection molding machine






ATOZ350-IS70

  • Clamping force : 350 kN
  • Distance between tie-bar : 280 x 280 mm
  • Screw diameter : 18 / 22 mm
  • Injection volume : 25 ~ 37 cm³
Add to inquiry

ATOZ700-IS170

  • Clamping force : 700 kN
  • Distance between tie-bar : 360 x 360 mm
  • Screw diameter : 22 / 25 / 28 mm
  • Injection volume : 56 ~ 92 cm³
Add to inquiry

ATOZ1000-IS250

  • Clamping force : 1000 kN
  • Distance between tie-bar : 410 x 410 mm
  • Screw diameter : 25 / 28 / 32 mm
  • Injection volume : 83 ~ 136 cm³
Add to inquiry

ATOZ1400-IS430

  • Clamping force : 1400 kN
  • Distance between tie-bar : 460 x 460 mm
  • Screw diameter : 30 / 35 / 40 mm
  • Injection volume : 134 ~ 238 cm³
Add to inquiry

ATOZ1800-IS630

  • Clamping force : 1800 kN
  • Distance between tie-bar : 510 x 510 mm
  • Screw diameter : 35 / 40 / 45 mm
  • Injection volume : 211 ~ 349 cm³
Add to inquiry
